4K Prime NovaStar
The 4k- Prime is NovaStar’s all-in-one controller that features excellent video processing, control capabilities, and LED screen configurations. NovaStar’s V-Can smart control software allows for faster and simpler operations with the 4K-Prime, in addition to enabling richer image mosaic effects. The 4K-Prime is an excellent choice for fine-pitch LED displays, conference rooms, event spaces, exhibition locations, and other high-end rental applications.
A variety of inputs: 1 × DP 1.2, 1 × HDMI 2.0 and 4 × DVI
More output connectors, larger loading capacity
Provides 16 × Neutrik Ethernet outputs and 4 × optical fiber outputs, with loading capacity up to 10,400,000 pixels
DVI mosaic
HDR output
Up to 4 4K-Prime units can load a super-large screen.
V-Can (smart control software from NovaStar) supported
EDID management supported
Personalized image scaling: Full screen, pixel to pixel and custom
Customized BKG settings: Pure color BKG and BKG image
Whatsapp Us
| Connector | Quantity | Description |
|---|---|---|
| DVI | 4 | Four DVIs are all single-link DVI connectors by default -Each DVI: Input resolutions up to 1920×1200@60Hz |
| DP 1.2 | 1 | Input resolutions up to 3840×2160 @60Hz |
| HDMI 2.0 | 1 | Input resolutions up to 3840×2160 @60Hz |
| Connector | Quantity | Description |
| Ethernet port | 16 | 16 × Gigabit Ethernet output connectors, allowing for a loading capacity up to 10,400,000 pixels |
| OPT 1–4 | 4 | 4 optical fiber connectors support copy and hot backup modes when used for output simultaneously. OPT 1 transmits data of Ethernet ports 1–8. OPT 2 transmits data of Ethernet ports 9–16. OPT 3 & 4 serve as the copy/hot backup for OPT 1 & OPT 2 respectively. |
| MONITOR | 1 | HDMI connector for output monitoring Resolutions up to 1920×1080@60Hz |
| Connector | Quantity | Description |
| ETHERNET | 1 | Connect to PC for communication, or connect to Web for device control |
| USB (Type B) | 1 | Connect to PC for debugging. Used as the input connector to connect another 4K-Prime unit |
| USB (Type A) | 1 | Connect to the central control device |
| RS232 | 1 | For device program update |
| Type | Description | |
| Power Connector | AC100V~240V 50/60Hz | |
| Operating temperature | 0°C to 50°C | |
| overall Power Consumption | 70 W | |
| Dimensions | 482.6 mm × 373.0 mm × 94.6 mm | |
| Package dimensions (flight case) | 550.0 mm × 561.0 mm × 155.0 mm | |
| Net Weight | 6.2 kg | |
| Total Weight | 18 kg | |
